Model: PCB Unloader
Brief: SMT, SMT PCB Unloader, SMT Unloader, PCB Unloader, PCB Unloader
Details
1. Microcomputer control, stable and reliable.
2. LCD screen display, menu interface, the man-machine dialogue is convenient.
3. Many sound-light alarm function.
4. So can use standard feeder, strong commonality.
5. According to the thickness of the PCB so set feeder lifting step distance.
6. Under so feeder built-in push board institutions, avoid buy separate push trigger.
7. Automatic counting functions, facilitate production statistics.
8. Signal communication interface, and other machines online travel.
PCB Magazine loader for/SMT assembly line PCB Conveyors -Product Description:
| Model: | YS-3525 |
| Specifications | Loader/Unloader |
| Loader Dimension(L*W*H) | 1650x730x1250mm |
| Unloader Dimension(L*W*H) | 2450x730x1250mm |
| Electric Supply Required | 2phase, 220V 50/60Hz |
| Weight | Approx. 230KG |
| Pitch Selection | 10, 20, 30, 40, 50mm |
| Magazine Size | 355x320x565mm |
| Power Consumption | 240W |
| Max. Width Of PCB | 300mm (Option: 410mm ) |
| Converyor Height | 900+/-20mm |
| Air Supply | 4.5-6Kg/cm2 |
