YSL - G5 Function Introduction

1. Image and optical path system
The new optical path system--uniform ring light and high-brightness coaxial light, together with the brightness function that can be adjusted steplessly, makes all types of Mark points (including uneven Mark points) can be well identified. Tin-plated, copper-plated, gold-plated, tin-sprayed, FPC and other types of PCBs with different colors. YSL's patented mathematical operation model ensures that the machine can achieve high-precision alignment and can achieve 01005 printing.

2. Simple and easy-to-use humanized Chinese/English operation interface
Using windows XP operation interface, it has good man-machine dialogue function; especially in the navigation effect of program files, it is convenient for all operators to quickly familiarize with the operation; menu type Chinese/English switching, operation log, fault record/fault self-diagnosis/fault analysis Prompt/light alarm and other functions make the operation simple and convenient.

3. High adaptability steel mesh frame clamping system
Realize the printing of various sizes of screen frames, and can realize the rapid replacement of models in the production process.

4. YSL special adjustment jacking platform

5. Cleaning system
The system provides three cleaning methods: dry cleaning, wet cleaning and vacuum cleaning. These three methods can be used in any combination, and when the customer does not need automatic cleaning, manual cleaning can be realized under the production interface, thereby reducing cleaning time and improving production. efficiency. The new wiping system ensures full contact with the steel mesh, and the large vacuum suction ensures that the residual solder paste in the mesh can be vigorously eliminated, and an effective automatic cleaning function is truly realized. The CCD part and the cleaning part are separated, when the CCD works, the CCD part moves independently, which reduces the load of the servo motor and improves the movement speed and precision of the machine.

6. 2D solder paste printing quality inspection and analysis
It can quickly detect printing problems such as offset, less tin, missing printing, and continuous tin to ensure printing quality
